1. Raw Material Reception & Pre-processing

Fruits are delivered, dry-cleaned, and sorted by size/ripeness using optical sensors or manual inspection to remove defects.

High-pressure washing (bubble, brush, or spray systems) removes dirt, pesticides, and surface microbes.

2. Crushing & Juice Extraction

Fruits are crushed or pulped (e.g., hydraulic pressing for apples, gentle reaming for citrus) to break down cellular structure.

Extraction methods (cold press, centrifugal, or enzymatic treatment) are selected based on fruit type to maximize yield and preserve nutrients.

3. Filtration & Clarification

Juice is passed through screens or centrifugal separators to remove pulp, seeds, and solids.

For clear juices, enzymatic clarification or ultrafiltration may be applied.

4. Pasteurization & Preservation

Heat treatment (e.g., HTST pasteurization at 72°C/15s or UHT at 135–150°C) eliminates pathogens and inactivates enzymes.

Alternative methods like HPP (High-Pressure Processing) are available for premium NFC juices.

5. Blending & Homogenization (Optional)

Juices are blended to achieve target Brix levels, flavors, or functional additives (e.g., vitamins).

Homogenization ensures uniform texture by breaking down pulp particles.

6. Packaging & Storage

Juice is filled into sterile containers (bottles, cans, or pouches) via automated hot-fill or aseptic systems.

Our integrated machinery supports the entire production journey—from raw fruit handling to packaging—enabling businesses to create a diverse range of juices, including NFC (Not-From-Concentrate), pasteurized, UHT-treated, and functional blends tailored to regional preferences.

We specialize in customizable production lines that adapt to varying capacities, from small-scale local processors to large industrial facilities. Our solutions incorporate key technologies such as intelligent sorting, high-yield extraction, gentle pasteurization, and sterile packaging, ensuring optimal nutrient retention, extended shelf life, and consistent flavor profiles.

By leveraging robust food-grade stainless-steel machinery and smart control systems, we help you achieve operational excellence while reducing labor costs and energy consumption. Whether you process tropical fruits like mango and pineapple or citrus and berries, our equipment maximizes yield (up to 90% extraction) and minimizes waste (<4%). Trust us to deliver turnkey juice processing systems that empower your growth in the competitive global beverage market.
