Product Details

Working Principle

The Crusher operates via a high-speed rotating knife assembly driven by a high-power motor. Raw materials enter through a sealed hopper and are drawn into the cutting chamber. Here, rapidly spinning alloy steel knives shear and impact the material, reducing it into smaller particles. Final particle size is regulated by adjusting the stainless steel screen aperture (ranging from 0.5–12mm), ensuring uniform output. Once crushed, material passes through the screen and exits via the discharge chute, with the entire process controlled for efficiency and consistency.

Features

Hygienic & Durable:

Food-grade 304/316 stainless steel construction prevents corrosion and simplifies cleaning, meeting global safety certifications.

High-Performance:

Equipped with a 5.5–30kW motor and sharp, long-lasting alloy steel knives for efficient processing of tough materials (e.g., frozen meats, nuts).

Safe & Flexible:

Safety interlock systems halt operation if the hopper is open; adjustable screen sizes enable customized output (from fine powders to coarse chunks).

Low Maintenance:

Tool-free disassembly for quick cleaning; optional soundproof enclosures reduce noise levels.

Technical Highlights

Leveraging advanced engineering, the Crusher features a heavy-duty motor with optional variable frequency drive (VFD) for speed control, optimizing energy use and throughput (50–1500kg/h).

The knife assembly uses precision-machined, interchangeable alloy steel blades to extend service life.

The screening system employs easy-lock food-grade stainless steel meshes for rapid size adjustments. Certified to CE/ISO standards, it can be configured with PLC automation for batch processing and real-time monitoring.

Application Fields

Ideal for the food industry, this Crusher processes a wide range of materials:

Nuts & Grains:

Almonds, walnuts, wheat, corn, etc.

Meats & Sugars:

Frozen meats, sugar lumps, candies.

Bakeries & Spices:

Producing breadcrumbs, powdering dried herbs.
Its versatile design suits small startups, mid-sized factories, and large-scale industrial plants, streamlining production workflows and ensuring consistent quality output.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
