Product Details

Working Principle

Liquids with dissolved gases enter the tank. Under vacuum (maintained by a vacuum pump or steam ejector, typically at -0.095 MPa to -0.1 MPa), the liquid's boiling point drops, causing gases to form bubbles and rise. The vacuum system continuously extracts these gases, while degassed liquid exits via the bottom outlet. Optional spray nozzles or fillers increase surface area for faster degassing; the sealed design ensures stable vacuum levels throughout the process.

Features

High-efficiency vacuum system:

Stable pressure control for reliable gas removal.

Food-grade construction:

304/316L stainless steel for corrosion resistance, sanitary tri-clamp connections, and easy cleaning.

Automated control:

PLC + HMI interface for real-time monitoring of vacuum, temperature (if with heating jacket), and liquid level.

Modular design:

Easy installation/maintenance, customizable with heating/cooling jackets or CIP (Clean-In-Place) systems.

Robust sealing:

Prevents leakage and contamination during operation.

Technical Highlights

Vacuum engineering:

Utilizes rotary vane, Roots, or water ring vacuum pumps to create low-pressure environments.

Internal optimization:

Spray nozzles, fillers, or agitators maximize gas-liquid contact for efficient degassing.

Thermal control:

Jacketed heating/cooling systems (with thermal oil or steam) handle temperature-sensitive materials.

Compliance:

Materials and design meet FDA/3A/HACCP standards for food safety; control systems ensure data traceability.

Application Fields

Food industry: Degassing syrup, concentrated juice, tomato sauce, or viscous liquids to prevent browning, maintain flavor, and improve texture.

Beverage manufacturing: Removing oxygen from water/juice before filling to extend shelf life and preserve freshness.

Pharmaceuticals: Degassing solutions for injections or syrups to ensure purity and stability.

Chemical & Cosmetics: Eliminating air bubbles in resins, adhesives, or creams to enhance product quality and stability.

This equipment is essential for any process requiring gas-free liquids, delivering consistent performance and quality assurance in global industrial applications.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
