Product Details

Working Principle

Bottles are automatically fed into the filling station via a conveying system. Once precisely positioned, filling nozzles lower and dispense liquid according to preset volume/weight parameters. A high - precision metering system (e.g., volumetric or weighing technology) ensures consistent fill levels. Post - filling, bottles are moved to subsequent processes (e.g., capping, labeling). The entire cycle is orchestrated by a programmable logic controller (PLC) for efficient, stable automation.

Features

High - precision filling：

Servo motors/pneumatic components control filling speed and volume, minimizing errors.

Intelligent operation：

The HMI simplifies parameter setup and process monitoring, with multi - recipe management support.

Hygienic & durable：

Food - grade stainless steel construction resists corrosion, eases cleaning, and complies with food safety regulations.

High - efficiency output：

Multi - nozzle design suits batch production for SMEs, with adjustable speeds.

Broad compatibility：

Adapts to varied bottle specifications (diameter, height) and liquid types (viscous, free - flowing).

Technical Highlights

Integrating cutting-edge technologies like PLC control systems (Siemens/Omron), servo motor-driven motion control ensures precision. Optional weighing technology (load cell+controller) or volumetric metering (piston/rotary pump) guarantees accuracy. Safety features include emergency stop buttons and photocurtains, while electrical cabinets meet IP65 protection standards for reliable performance in tough environments. Premium pneumatic components (SMC/FESTO) ensure reliable nozzle actuation.

Application Fields

Food (sauce, oil, juice);

Beverage (wine, dairy);

Chemical (cleaners, reagents)

Pharmaceutical (syrup, disinfectants);

Other Industries involving bottled liquids.

It handles low - to medium - viscosity liquids, making it vital for SMEs seeking automated production and quality enhancement.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
