Product Details

Working Principle

The machine operates through a continuous, automated流程:

Film Feeding & Bag Forming: Roll film unwinds and passes through a forming tube, creating tube-shaped bags.

Metering & Filling: Product (powders, granules, or bulk items) is weighed precisely by a dosing system (e.g., screw feeder, volumetric filler) and dispensed into formed bags.

Sealing & Cutting: Horizontal and vertical sealing jaws seal the bag, while a cutting mechanism separates individual packages.

Date Printing (Optional): Real-time date/lot codes are printed on bags before sealing.

Features

High Precision & Speed:

Servo motor-driven systems ensure accurate weight control (±0.5-1%) and high output (up to 40-60 bags/min, depending on bag size).

User-Friendly Operation:

Touchscreen HMI simplifies parameter settings, recipe management, and real-time monitoring.

Modular & Flexible:

Interchangeable dosing units accommodate various materials (powders, pellets, liquids, etc.).

Safety & Hygiene:

Stainless steel construction (IP65 protection) meets food safety standards; automatic lubrication reduces maintenance.

Automatic Detection:

Photoelectric sensors detect film marks for precise bag length control, with auto-adjustment for empty bags.

Technical Highlights

Control System:

PLC + touchscreen interface, supporting remote diagnostics and data logging.

Packaging Materials:

Compatible with BOPP/LDPE, PET/ALU/PE, and other composite films (thickness: 0.06-0.12mm).

Bag Types:

Supports pillow bags, gusseted bags, zipper bags, and more (bag size: 50-400mm width, 80-500mm length).

Modular Design:

Customizable configurations (e.g., nitrogen flushing, inkjet printing) for diverse industry needs.

Application Fields

Ideal for:

Food industries (flour, sugar, coffee, rice, frozen foods);

Agricultural sectors (seeds, fertilizers, animal feed);

Chemical sectors (detergents, additives).

It efficiently packages powdery (e.g., milk powder), granular (e.g., nuts), or bulk solid materials (e.g., flour), meeting global packaging standards for export markets.

This machine combines efficiency, flexibility, and durability, making it a core solution for businesses seeking to optimize packaging productivity and quality.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
