Product Details

Working Principle

Food items are transported via a mesh belt conveyor into a stainless steel fryer tank filled with heated oil (electric or gas-powered). A PID-controlled digital thermostat maintains oil temperature within ±1°C of the set point, ensuring even frying. Once the preset cycle time is complete, the belt lifts the fried products into a drain zone to remove excess oil before exiting. Optional integrated oil filtration systems purify used oil, reducing waste and operating costs.

Features

Construction:

Full 304/316 stainless steel body, compliant with FDA/NSF hygiene standards.

Control System:

User-friendly touchscreen HMI with recipe storage, data logging, and real-time monitoring.

Conveyor:

Variable-frequency drive (VFD)-controlled mesh belt for precise speed adjustment; open-mesh design minimizes oil carryover.

Safety:

Emergency stop buttons, over-temperature cutoffs, low oil level alarms, and insulated guards.

Cleaning:

CIP-ready design, sloped drain surfaces, and quick-release panels for efficient sanitation.

Energy Efficiency:

Insulated fryer tank and high-efficiency heating elements reduce energy consumption.

Technical Highlights

Temperature Control:

PID regulators ensure ±1°C precision for consistent frying.

Automation:

PLC/HMI technology enables recipe management, data export, and remote diagnostics.

Oil Management:

Built-in filtration (manual/automatic) and oil lifespan monitoring extend oil usability.

Materials:

Food-contact zones use 316L stainless steel with electropolishing for corrosion resistance.

Safety Tech:

Interlocked safety guards and optional automatic fire suppression systems.

Application Fields

Ideal for high-volume food processing sectors:

Frozen food manufacturing (fries, chicken nuggets, fish sticks)

Snack food production (chips, crackers, donuts)

Industrial bakeries (pastries, cakes)

Seafood processing (fish cakes, tempura)

Export-oriented food plants requiring large-batch, consistent frying.
Also suitable for central kitchens, large restaurants, and co-packing facilities needing scalability and quality control.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
