Product Details

Working Principle

The Sterilization Storage Tank operates via a controlled SIP (Sterilization In Place) process. Initially, the target liquid is pumped into the tank. Then, a sterilizing medium (e.g., saturated steam or overheated water) is introduced into the jacketed layer or direct - contact zones. A PLC - based control system activates pre - programmed SIP cycles, heating the tank’s interior—including walls, piping, and agitators (if equipped)—to a preset temperature (usually 121°C or higher) and holding it for a specified duration (e.g., 30 minutes). Post - sterilization, the system cools via circulating cold water in the jacket. Throughout the cycle, sensors continuously log temperature, pressure, and other parameters, ensuring thorough sterilization and enabling data traceability.

Features

Hygienic Design & Materials:

Constructed from 304/316L stainless steel, with electropolished inner surfaces (roughness <0.5μm) and crevice - free welds, it prevents microbial buildup and complies with FDA/3A standards.

Efficient SIP Functionality:

Customizable sterilization programs (temperature, time) ensure comprehensive decontamination for diverse applications.

Superior Insulation:

Jacket filling (e.g., rock wool) or vacuum insulation minimizes heat loss, maintaining stable temperatures and reducing energy consumption.

Smart Automation:

A PLC system with an HMI interface enables automated SIP cycles, real - time monitoring, and data logging for regulatory compliance.

Robust Safety:

Equipped with pressure relief valves, over - temperature cutoffs, and emergency stop switches to ensure safe operation during all phases.

Technical Highlights

Manufacturing Precision:

Automated welding, mirror - finished surfaces, and rigorous quality control guarantee structural integrity and ease of cleaning.

Regulatory Compliance:

Designed to meet international certifications like CE, FDA, and 3A for material safety, electrical safety, and operational reliability.

Customization & Scalability:

Available in capacities ranging from 100L to 10,000L, with optional features such as agitation systems, CIP (Clean In Place) interfaces, and load cells for weighing.

Data Traceability:

The control system records SIP cycle parameters, generating audit - ready reports for quality assurance and regulatory inspections.

Application Fields

This tank is vital in industries where sterile storage is non-negotiable:

Food & Beverage: Ideal for storing sauces, syrups, concentrated juices, and edible oils after heat treatment to prevent microbial spoilage.

Dairy Processing: Maintains the sterility of pasteurized milk, yogurt blends, and cheese solutions during intermediate storage before packaging.

Pharmaceuticals: Essential for storing sterile drug solutions, buffers, and culture media in compliance with GMP (Good Manufacturing Practice) standards.

Biotechnology: Used for preserving cell culture fluids, vaccines, and biological intermediates in biopharmaceutical manufacturing to ensure product purity.

This equipment is a core asset for any facility requiring reliable, large - scale sterile liquid storage across global markets.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
