Product Details

Working Principle

The machine adopts a fully automated workflow. Products are fed onto the conveyor belt via a sorting device to ensure orderly entry. A photoelectric sensor detects the product's position and triggers the labeling mechanism. Labels are dispensed from the roll, guided by a labeling head that synchronizes with the conveyor speed. The labeling head precisely places labels on the product surface, while a rubber roller or brush ensures smooth adhesion. After labeling, products exit through the conveying system, and the PLC (Programmable Logic Controller) centrally manages all actions to guarantee consistency.

Features

High Precision & Efficiency:

Equipped with high - precision sensors and a servo motor - driven system, it achieves ±1mm labeling accuracy and a speed of 40 - 120 pcs/min (depending on product size).

User - Friendly Operation:

A 7 - inch color touch screen simplifies parameter settings, label length adjustment, and production monitoring.

Wide Compatibility:

Adapts to round bottles, square bottles, flat boxes, and irregular - shaped containers, supporting multiple label materials (paper, film, foil, etc.).

Stable Performance:

Stainless - steel frame and wear - resistant components ensure long - term operation; overload protection and emergency stop functions enhance safety.

Technical Highlights

Core Drive:

Servo motor + PLC control system ensures synchronization of conveying, labeling, and rewinding.

Label Control:

Stepless speed - adjustable AC motor for stable label feeding; automatic label - breaking device for die - cut labels.

Intelligent Control:

Supports label counter, product counter, and fault self - diagnosis; data storage function saves up to 50 labeling tasks.

Application Fields

Primarily used in the food & beverage industry for labeling tasks such as:

Bottled/jarred products (juices, sauces, dairy, pickles).

Boxed items (cereals, snacks, tea packages).

Pouches or bags (coffee, flour, pet food).

Also applicable to cosmetic, chemical, and pharmaceutical sectors for container labeling, making it a versatile solution for global manufacturing needs.

vAll machines can be customized to meet your specific requirements. Contact us for more details!
